技术 - Article 2024.06.19

Application Guide > Automotive > 48V System

为提高汽车的燃油效率(电池效率) ，增加电压48V电池辅助已成为趋势，因此用于电源线上的100VMLCC的小型化，高容化的需求在逐步增加。



为优化产品设计，三星电机正在扩大100V,小型高容值MLCC的line up，以减少MLCC零件数量及为set小型化做出贡献。



MLCC 趋势 : 100V额定电压, 小尺寸 & 高容值

▷ 小型化

▷ 高可靠性

 → 推荐方案 :  X7* PN Series



Size

(inch/mm)

Rated Voltage

[Vdc]

TCC

Capacitance

Part Number

MP

Status

Sample

Availability

1210/3225

100

X7S

10㎌

CL32Y106KCV6PN#

In MP

Available

1210/3225

100

X7R

4.7㎌

CL32B475KCI6PN#

In MP

Available

1206/3216

100

X7S

4.7㎌

CL31Y475KCK6PN#

NEW

Available

1206/3216

100

X7R

2.2㎌

CL31B225KCHVPN#

In MP

Available

0805/2012

100

X7S

1.0㎌

CL21Y105KCYVPN#

In MP

Available

0805/2012

100

X7R

0.47㎌

CL21B474KCYVPN#

In MP

Available

0603/1608

100

X7S

0.22㎌

CL10Y224KC86PN#

Under

Development

Available

0603/1608

100

X7R

0.1㎌

CL10B104KC8VPN#

In MP

Available
