技术 - Article 2024.09.20

Application Guide > Automotive > Smart Key ECU

智能钥匙ECU(Electronic Control Unit)内置在汽车电子设备上,与智能钥匙收发信号,控制系统。



因此,在生成LF信号并通过天线向车辆周围发送信号的电流回路中,为了防止干扰并很好地传达信号,要求采用DC-Blocking用电容。



介绍适用于此应用的三星电机Low IZl, C0G, 0805 inch MLCC系列。





MLCC 趋势 : Low lZl, 小型化

▷ DC信号屏蔽

▷ 损耗降低

▷ 高可靠性

  → 推荐方案 :  C0G PN系列



Size

(inch/mm)

Rated Voltage

[Vdc]

TCC

Capacitance

Part Number

MP

Status

Sample

Availability

0805/2012

50

C0G

10㎋

CL21C103JBF1PN#

In MP

Available

0805/2012

50

C0G

22㎋

CL21C223JBQ1PN#

NEW

Available

0805/2012

50

C0G

33㎋

CL21C333JBQ1PN#

NEW

Available
