Chip Resistor

High Power Resistor

Product Search Component Library Buy Now

高いパワー印加可能なResistor

一般品（General）に比べて高いPowerを印加できる製品で、3倍程度高いPower特性を有します。
サムスン電機は、独自の技術を用いて抵抗体の面積を最大化することで、他社に比べて高い特性を実現します。

Product Search
New Core Technology
を取り入れ、最高の性能を実現
  • 抵抗体の長さ拡大
    抵抗体にLaserで
    Serpentine Cutを適用
  • 抵抗体の面積拡大
    印刷とLaser Cuttingにより、抵抗体の面積を3倍拡大
  • 抵抗体の均一な
    厚みを実現
    独自の印刷工法により、
    均一な抵抗体厚みを実現

High Power

High Power Lineup - Type, Size Inch/(mm), Feature, Watt [W], Resistance Tolerance[%], Resistance Range, Operation Temperature Range [℃]
Type Size Inch/(㎜) Feature Watt [W] Resistance
Tolerance [%]		 Resistance
Range		 Operation
Temperature
Range [℃]
RCW0603 0201(0603) 1/10 ±0.5%
±1%
±2%
±5%		 1~10MΩ -55~125℃
RCW1005 0402(1005) 1/5
RCW1608 0603(1608) 1/4 -55~155℃
RCW2012 0805(2012) 1/2
RCW3216 1206(3216) 1

Automotive High Power

Automotive High Power Lineup - Type, Size Inch/(mm), Feature, Watt [W], Resistance Tolerance[%], Resistance Range, Operation Temperature Range [℃]
Type Size Inch/(㎜) Feature Watt [W] Resistance
Tolerance [%]		 Resistance
Range		 Operation
Temperature
Range [℃]
RAW2012 0805(2012) 1/2 ±0.5%
±1%
±2%
±5%		 1~10MΩ -55~155℃

適用分野

Lineup
